Reasonable price Grain Silo Corrugated Sheet Production Line - Grain bin silo stiffener making machine – Thomas Detail:
1.Drawing of the profile of the silo stiffener:
(Machine can be customized according to your needs, the following picture is the drawing provided by our customer, for reference only.)
2.Finished Product:
3.Working process of the production line:
Hydraulic unwinder —– Shovel device (auxiliary feed + leveling) —– Pre-cutting – Main forming machine —– Telescopic support – Hydraulic punching device – Moving pallet —– CNC bending Hydraulic – Hydraulic cutting – receiving table
4. Machine Pictures:
5. Machine Details :
|
Description |
||
|
Production name |
Silo Stiffener Forming Machine |
|
|
Machine floor area |
About 25.5m*2m（L*W） |
|
|
Feeding direction |
left in, and right out |
|
|
Voltage parameter |
380v,50Hz, 3 phase |
|
|
Hydraulic oil |
46# hydraulic oil |
|
|
Gear oil |
18# hyperbolic gear oil |
|
|
Shaft diameter |
120mm |
|
|
Shaft Material |
40Cr, quenching and tempering |
|
|
Rack |
Gantry type (Memorial archway type) |
|
|
Rack material |
Nodular cast iron |
|
|
Punching die material |
SKD11 |
|
|
Rack quantity |
18 rows |
|
|
Drive mode |
Gear box drive |
|
|
Working speed |
about 1 piece/min |
|
|
Transmission mode |
Each rack with a gear distribution box drive |
|
|
Forming roller |
GCr15, quenching, the hardness of HRC56-62 º |
|
|
Motor power |
45 KW *2 Siemens brand |
|
|
Machine color |
Machine base |
As required |
|
Rack and gear box |
As required |
|
6. After-sales service :
1) . User manuals / videos on installation, adjustment, setup and maintenance of the machine will be provided.
2). The machine is with Wi-Fi function, our technicians will help to work if the machine has a problem.
3). when the borders are open, we will send technicians to your factory for training. (The cost is paid by the seller.)
4). Warranty 2 years (Excluding man-made damage)
5). Delivery time: 90 working days.
6). Machine price: contact us.
