Grain Bin Silo top panel production line

Short Description:

Contacts: Ms. Elise
Work Phone: +86 15232975068
Email: elise@tgrollforming.com
WhatsApp: +86 15232975068
WeChat: +8615232975068
Skype: babygirlelise2


Product Detail

Product Tags

Silo cap machines : Nowadays in the world , grain storage bin space demands is increasing, and the demand for silo tanks is rising as well. Our silo roof production lines are in need to meet the growing demand. We offer fully automatic systems to produce the finished silo roofs, which includes decoiler, feeding, cutting, roll forming, punching, receiving.
1. Silo Roof Profile Drawing:

(Machine can be customized according to your needs, the following picture is the drawing provided by our customer, for reference only .)






2.Finished Product:



webwxgetmsgimg (17).jpg






3.Working process of the production line:



Decoiler—leveling—cutting with angle —servo displacement rolling shear—double layer conveying roller table—single layer conveying roller table —pneumatic pressing—CNC servo punching 1#—roll forming machine 1#—conveying roller table —CNC servo punching 2#—rolling forming machine 2#—conveying roller table—pneumatic suction and palletizing



4. Machine Pictures:




















5. Machine Details :



 No

  Name

 Number

  1

 10 tons hydraulic automatic decoiler (with feeding trolley)

 1 set

  2

  Leveling machine

 1 set

  3

 Angle cutting machine

 1 set

  4

 Servo displacement rolling shear (with pinch roller)

 1 set

  5

 10m double-layer conveyor roller table (equipped with stopper, turn over, guide device)

 1 set

  6

 8m single-layer conveyor roller (with guide positioning)

 1 set

  7

 Double-station angle punching machine (including cutting small head waste)

 2 set

  8

 8m conveying roller table (with guiding positioning, pneumatic pressing and feeding device)

 1 set

  9

 Roll forming part 1#

 1 set

  10

 CNC servo punching machine 1#

 1 set

  11

 15m conveyor roller

 1 set

  12

 8m conveying roller table (with guiding positioning, pneumatic pressing and feeding device)

 1 set

  13

 CNC servo punching machine 2#

 1 set

  14

 Roll forming part 2#

 1 set

  15

 15m conveyor roller platform

 1 set

  16

 8m conveyor roller platform (with guide and positioning device)

 1 set

  17

 Automatic palletizer

 1 set

  18

 Electric control system

 1 set

  19

 Pneumatic system

 1 set

  20

 Hydraulic system

 1 set



6. After-sales service :



1) . User manuals / videos on installation, adjustment, setup and maintenance of the machine will be provided.

2). The machine is with Wi-Fi function, our technicians will help to work if the machine has a problem.

3). when the borders are open, we will send technicians to your factory for training. (The cost is paid by the seller.)

4). Warranty 2 years (Excluding man-made damage)

5). Delivery time: 90 working days.

6). Machine price: contact us.
